Canva Hackathon Devlog 👩‍💻

  • I didn't end up completing the hackathon project due to personal reasons but I did learn a lot about the Canva AppSDK and AppUIKit

Day 4

Day 3

  • Reading and learning more about the CanvasAPI and its capabilities

    • Web APIs > Canvas API | mdn web docs - fallback content (for accessibility) should be provided within the <canvas> element

      <canvas>
  <!-- Fallback -->

  Which can be text, an image, etc.
  <img src="..." alt="..." />
</canvas>

      • Rendering Contexts - there are two kinds, i think: 2d and 3d -const ctx = canvas.getContext("2d")

      • <canvas> only supports drawing rectangles and paths

      • the Bezier and quadratic curves look pretty interesting and they even have an example with a speech bubble!

      How to draw a path in HTMLCanvas
      function draw() {
  const canvas = document.getElementById("canvas");
  if (canvas.getContext) {
    const ctx = canvas.getContext("2d");

    ctx.beginPath(); // 1. Create a path
    ctx.moveTo(75, 50); // 2. Use drawing commands - moveTo: starting point for path
    ctx.lineTo(100, 75); //    lineTo: drawing lines from the point before to the argument point
    ctx.lineTo(100, 25);
    ctx.fill(); // 3. You can stroke and/or fill the path to render it
  }
}
      • after calling beginPath() the first command is always treated as a moveTo(), regardless of what it actually is
      • any open shapes are closed automatically when calling fill()
        • BUT NOT stroke() - so you still have to call closePath() for stroke()

  • Decision Point: I think I'll be going down the route of using Path2D Objects rather than the native CanvasAPI drawing commands as it is interchangeable with SVG paths which could be used to create ShapeElements instead of AppElements

  • I also explored PaperJS, a library for Vector graphic scripting - their examples look suuuper cool

    • this example gives me an idea for another Canva App that generates graphics based off of audio :3
    • Weird Faces by Matthias Dörfelt is of procedurally generated faces made with PaperJS and low key haunt me but also, it's like so relevant to how AI is generated images and faces these days - but this was work was made in 2012/13 :O
      • Weird Faces by Matthias Dörfelt

Day 2

  • Decently significant has been made!
  • Features I've Implemented:
    • adding/setting width and height of bubble
    • adding main text
    • adding background color
    • adding border color
    • adding border thickness
    • adding border radius
  • How it started
    • basically, the boilerplate that adds a text element onto the page
  • How it's going
  • The developer experience using the AppSDK and AppUIKit has been really nice thusfar 😍
    • I really like that the UIKit is in a storybook with every single example clearly listed out and the grouping and use is so intuitive and easy-to-use
  • I'm not sure if I should be using an AppElement or ShapeElement for the speech bubble. I've been using the AppElement so far and noticed the following:
    • it uses HTMLCanvas
      • it's my first time using the CanvasAPI 🖼️👓
    • it generates an image and it gets blurrier/degrades in quality when resized bigger in the editor
    • the colors can't be customised using Canva's UI (but can be customised using through the AppSDK)
      • the difference is that the preview of editing would be in the "Preview" section on the left vs where the actual element is on the screen
      • and there would also have to be additional code written to implement this editing feature; because if I'm not mistaken, editing an AppElement is just replacing it with a new one so you'd have to replace it in the right spot? A problem for future me to solve :))
      • I think I'd add an option to toggle between the two in some "Advanced Settings" section
  • I think I'd keep the text as just a TextElement so it can be customised and animated using Canva's existing text features
  • I could be going in over my head but I think I might want to make another app that is even more complex for the hackathon O.o

Day 1

  • I'll be joining the Canva AI and Integrations Hackathon
    • I'm joining it a little late (there are 19 days left atm and the hackathon started about a month ago lol) Hackathon Deadline in 19 Days
  • I'd usually do a little brainstorm and planning in Miro but since it's a Canva hackathon, I'm using Canva's Whiteboard feature 🙌
  • Dev Experience: Ngl, it was a bit of a struggle to figure out where to go to find specific information about things because not all things Canva-Developers-related is in the same URL. The key links I've bookmarked for this hackathon:
